OUTLOOK forward-mounted scope night vision weapon sight is designed for use with high-precision sniper rifles. This forward-mounted scope night vision weapon sight is mounted in tandem at the front of a daylight scope, enabling high precision aiming and observation at night.
The pvs 14 lenses group includes pvs-14 objective lens and pvs-14 eyepiece. pvs-14 optical lens assembly is a universal optical lens that can be adapted to international standard night vision products
This straight-tube easy focus ED glass 10x50 binoculars for sale has become the favorite choice of many optical enthusiasts with its simple and atmospheric design style and stylish appearance.
15×50 long range binoculars
15×50 long range binoculars for military use has first-class optical effects. This long range binoculars for military use is a first-class binocular developed according to the requirements of all-weather use with reference to the characteristics of military telescopes of advanced countries in the world. This long range binoculars for military usean be used in a variety of harsh environmental conditions. Therefore, the long range binoculars for military use is widely used in many fields, and because of its excellent performance, high-end taste and great collection value and symbolic significance, this binocular is favored by all business gifts, bird watchers, and so on.
Performance characteristic:
1. Full-coated lens coating, sharp imaging.
2. Wide field of vision, large exit pupil diameter, long exit pupil distance.
3. The prism chamber drying bin protection, professional waterproof eyepiece, high sealing performance.
4. It adopts all metal structure and is durable.
5. It has target reticle, which can roughly measure the target distance and azimuth.
6. It fully meet the military standard (GJB) requirements for all-weather use.
7. Other optional magnification：12x42,10x50
Product Type | 15×50 | |
Magnification | 15× | |
Body material | aluminium alloy | |
Armor material | NBR+PVC | |
Color | Black | |
Resolution | ≤5.6″ | |
Objective lens Ø | Φ50 ± 1mm | |
Ocular lens Ø | Φ22 ± 1mm | |
Exit pupil Ø | Φ4mm ± 10% | |
Exit pupil distance (mm) | 18mm | |
Twilight factor acc. to DIN 58388 | 22.36 | |
Relative Brightness | 25 | |
Field of view (°) | 4° | |
Field of view (at 1000M) | 70m | |
Field of view (at 1000yds) | 210ft | |
Near focus | 9m | |
Diopter system | Right diopter ring | |
Interpupillary distance | 52～73mm | |
Focus System | Center Focus | |
Focusing lens | Focusing eyepiece | |
Diopter compensation | -4 To +4 Diopter | |
Focusing Adjustment | -4 To +4 Diopter | |
Prism System | Paul prism | |
Prism Glass Material | BaK4 | |
Optical Configuration | Objective lens | 2E1G |
Ocular lens | 4E3G | |
Lens Type | Spherical Lens | |
Optical Material | All optical glass | |
Lens coating | Coating Condition | Eyepiece, objective plated single broadband green film, blue film rest |
Coating Spec. | 420-680nm,R＜0.5%(AVG) 420-680nm,R＜1.0%(ABS) blue film 550nm（MGF2) | |
Prism coating | Coating Condition | Blue film |
Coating Spec. | 550nm（MGF2) | |
Coating Condition | ||
Coating Spec. | ||
SystemTransimission | ≥ 70% | |
Water/Fogproof | ▇ Yes □ No | |
Gas Filled | ▇ Nitrogen □ Other | |
Eye cup | Type | ▇ Twist up □ Fold down |
Material | NBR | |
Eye caps | Type | ▉ Siamese-style □ Monobloc □ Other |
Material | NBR+PVC | |
Obj. Cover | Type | □ Siamese-style ▉ Monobloc Other |
Material | NBR+PVC | |
Adapt to tripod | ▉ Yes □ No | |
Strap | ▉ Yes □ No | |
Soft case | Type | □ Neutral ▉ Proprietary □ Other |
Material | 1200D Oxford cloth | |
Strap | Type | □ Neutral ▉ Proprietary □ Other |
Material | 25mm Wide Ribbon | |
Cleaning cloth | ▉ Yes □ No | |
Instruction manual | ▉ Yes □ No | |
Packaging | ▉ Yes □ No | |
Size(Length×Width×Height) | 190x60x177mm | |
Weight approx | 925g | |
long range binoculars for military use binocular
Yes, we provide samples to check the quality. Customers need to pay sample fee. We can ship by international express.
Yes, we can make customer's brand or packing if customer needs. Just contact us freely if you need to do OEM.
Our company is located in Kunming , Yunnan Province, China. You are more than welcome to visit! Just contact us beforehand and you are sure to leave with a satisfactory answer.
Quality comes first. We have a professional quality control team and we always double check the quality before product shipment. We have put quality control and inspection on another level.
Just leave your contact info and detailed brochures will be sent to you by email, containing accurate and updated information about our products.
