False color is a crucial visualization tool in thermal imaging technology. By transforming intangible temperature information into vibrant colors, it greatly enhances the human eye's perception of temperature distribution and differences, helping engineers, doctors, firefighters, and other professionals quickly and efficiently identify problems, diagnose faults, and make decisions.
Core Concept: Making the "Invisible" Visible
The Essence of Thermal Imaging: Thermal imaging cameras detect the infrared radiation energy emitted by an object's surface. The magnitude of this energy is directly related to the object's temperature. The camera itself records a "thermal map" composed of different grayscale levels—brighter areas indicate higher temperatures, and darker areas indicate lower temperatures.
Below, I will introduce common color modes and their suitable environments in detail.
I. What are the common color modes (palettes) for thermal imaging cameras?
The core of a thermal imager is to convert infrared radiation (heat), invisible to the human eye, into a visible image. Different color modes of thermal imaging cameras are schemes for "coloring" different temperature ranges. There are mainly the following categories:
1. Iron Red / White Heat of Thermal Imaging Cameras
Description: This is the most classic and commonly used mode. In white heat mode, the higher the temperature, the brighter the white; the lower the temperature, the darker the gray, up to black. Iron red is a variation, displaying bright yellow/white at high temperatures and dark red/black at low temperatures.
Characteristics: Aligns with human intuition about "heat" (bright = hot), high contrast, suitable for observing details.
Applications: The most versatile, suitable for most scenarios, such as building inspection, electrical inspection, equipment maintenance, security patrol, etc.
2. Black Heat of Thermal Imaging Cameras
Description: The opposite of white heat mode. The higher the temperature, the deeper the black; the lower the temperature, the brighter the gray/white.
Features: In some environments, the human eye is more sensitive to bright objects against a dark background.
Applications: Nighttime wildlife observation (animals have high body temperatures and appear as black silhouettes in cool grass, making them less likely to be disturbed), some military or law enforcement applications (facilitating the detection of hot targets in dark environments).
3. High-Contrast Rainbow Color of Thermal Imaging Cameras
Description: Uses a wide range of colors from purple, blue, green, yellow to red to represent temperature changes. The color range is wide, resulting in extremely strong contrast.
Features: Highlights minute temperature differences, but the vibrant colors may obscure target outlines and details.
Applications: Scenarios requiring rapid identification of extremely small temperature differences, such as detecting tiny overheated components on circuit boards or locating minute leaks inside walls.
4. Polar Color of Thermal Imaging Cameras
Description: This is an optimized version of the high-contrast rainbow color. It uses fewer colors (typically blue, yellow, red, etc.), with each color representing a specific temperature range.
Features: While maintaining high contrast, the image is clearer than the rainbow color, and target outlines are easier to identify.
Applications: Industrial inspection (e.g., pipe insulation, solar panel hotspot detection), firefighting (observing temperature distribution of structures in a fire scene through smoke).
5. Lava of Thermal Imaging Cameras
Description: A very popular mode where the background is displayed in cool gray or blue tones, while high-temperature targets are displayed in bright red, orange, and yellow, resembling lava.
Features: High-temperature areas are very prominent, with strong visual impact and good detail retention.
Applications: Firefighting (clearly distinguishes high-temperature fire points from the surrounding environment), industrial high-temperature detection (e.g., metallurgy, boilers).
6. Arctic / Cool Colors of Thermal Imaging Cameras
Description: The opposite of the lava mode, using cool tones such as blue and cyan to represent high-temperature areas.
Features: Reduces glare and makes eye comfort when used in bright daylight.
Applications: Outdoor use during the day, such as hunting observation, outdoor search and rescue, and daytime power line inspection.
The Role of False Color: The false color function of thermal imaging camera maps different temperature ranges (or grayscale ranges) into distinctly different, vibrant colors. In this way, color differences (such as red, yellow, and blue) that the human eye is highly sensitive to replace the difficult-to-distinguish grayscale differences, making temperature distribution immediately apparent.
II. Color Adaptation of Thermal Imagers in Different Environments
Selection Principles: Temperature difference between the target and background, ambient light, and your observation focus.
Recommended Color Mode Selection Rationale for Application Scenarios:
Looking for subtle temperature differences? (e.g., checking for overheated components on a circuit board, defects in building insulation)
Prefer high-contrast color palettes: such as rainbow or iron red. These palettes have rich color transitions, amplifying minute temperature differences into noticeable color changes, making problem areas (hot or cold spots) stand out.
Quickly identifying targets in extreme high temperatures? (e.g., firefighters searching for trapped people in a fire, monitoring area intrusion)
Prefer single warm or bright color palettes: such as white-hot (high temperatures are bright white, very conspicuous) or lava/amber. These thermal imaging palettes minimize visual interference, allowing you to instantly lock onto the hottest target in a complex background.
Hopefully, this detailed guide will help you better use your thermal imager!
